MOBIL FAST 3330 B

Name: MOBIL FAST 3330 B
Brand: World Wide Parts
SKU: MOBILFAST3330B
Availability: OutOfStock

Production 130 m³/h – Twin shaft mixer 5000-3330 (yield concrete 3,33 m³ per cycle) - Mixer loaded by loading belt - Cabin - FULLY GALVANIZED - FOUNDATION WORKS NO NEEDED

Codice : MOBILFAST3330B

Quantity

Generic Description

Production 130 m³/h – Twin shaft mixer 5000-3330 - yield concrete 3.33 m³ per cycle (for more details, see the MEB catalog under "Technical Data Sheets") - Mixer loaded by loading belt - Cabin - FULLY GALVANIZED - FOUNDATION WORKS NO NEEDED.
N.1 AGGREGATE STORAGE BINS WITH N.4 COMPARTMENTS - CAPACITY 65-95 m³ (geometric-peak) - FULLY GALVANIZED.
N.1 INDIPENDENT SUPPORTING STRUCTURE OF AGGREGATES BINS (4 COMPARTMENTS) FOR MOBIL FAST 3330 B.
N.4 SETUP FOR THE INSTALLATION OF THE COVERING FOR THE AGGREGATES BINS (COST FOR SINGLE COMPARTMENT).
N.4 SETUP FOR THE INSTALLATION OF SAFETY BARRIERS (COST FOR SINGLE COMPARTMENT).
N.1 BETONWIN 3 + PC SIEMENS OR IBM + MONITOR 22``LCD+ LASER PRINTER.
N.1 SOFTWARE FOR MIXER OPERATING FOR BETONWIN/BETONSYSTEM (FOR TWIN SHAFT COMPULSORY MIXER OR PLANETARY MIXER) AND PASSIV WATTMETER FOR MIXER.
N.1 UPPER COVERING FOR BELT IN GALVANISED STEEL PANELS FOR MOBIL FAST 3000/3330 belt with width 1000 mm, length 15000 mm
N.1 LOWER COVERING FOR MOBIL FAST 2500B/3000/3330 for chevron belt with width 1000 mm, length 15000 mm.
N.1 WATER ADDING SYSTEM pulse counter with sphere valve of 1/2" for clean water - precision batching in case of mixer.
N.1 REMOTE TECHNICAL SUPPORT SERVICE FREE OF CHARGE DURING GUARANTEE PERIOD.
N.1 UPS (ON-LINE TYPE) Battery life 6/20 minutes.
N.1 MANAGEMENT IN MAINTENANCE MODE - MOBIL FAST 3000 B - 3330 B THROUGH ELECTROMECHANICAL CONTROLS - ON THE CONTROL PANEL OF THE BATCHING PLANT.
N.1 RINGS FOR SHAFTS CLEANING FOR TWIN SHAFT MIXER.
N.1 FILTER FOR MIXER - 14 m² FILTERING SURFACE.
N.1 FINISHING OF PAINTED COMPONENTS STANDARD COLOUR: RAL 9002 (GREY WHITE) / RAL 7015 (SLATE GREY).
N.1 GENERAL DESIGN SPECIFICATIONS FOR BATCHING PLANTS AND SILOS OF MAXIMUM DIAMETER 3500 mm.
All the components are designed for the following environmental conditions:
- Soil roughness: flat area with low vegetation, isolated obstacles 20 times the height from the installation site - Exposition Category II (Eurocode 1);
- Actions on structures:
snow load: 1.00 kN/m2
wind load: v= 28 m/s – 100 km/h;
- Ground type: type B, medium consistency soil, average shear waves velocity in the top 30 m: between 360 m/s and 800 m/s, NSPT > 50 blows / 30 cm in coarsed-grained ground and CU,30 > 250 kPA in fine-grained grounds (Eurocode 8);
- Seismic action: peak value of assumed horizontal acceleration of the elastic response spectrum for the lifesaving ultimate limit state: ag/g = 0,20; - Outside air temperature: within -5° (minimum winter temperature) and +40° (maximum summer temperature), unless for the supply of insulated claddings on the concrete plants and/or the silos;
- Importance Class: Class I, buildings with occasional presence of people (Eurocode 1).
Steel for structural use: S275 or better quality, hot-rolled profiles, in accordance with the EN 10025 standards.
Alloy steel: S235 or better quality, in accordance with the UNI EN 10025 standards.
