Upper caulked covering of the mixer unit for MOBIL FAST

Upper caulked covering for mixer (on four side with roof) ON THE MOBIL FAST plant made by caulked panel th. 40 mm with carrying structure and roof with only one sloping. Equiped with n.2 windows and n.1 access door. Covering structures, finishing: hot-dip galvanised.

PLEASE NOTE:

The conditions assumed for the design of each component:

- Ground type: type B, medium consistency soil, average shear waves velocity in the top 30 m: between 360 m/s and 800 m/s, NSPT > 50 blows / 30 cm in coarsed-grained ground and CU,30 > 250 kPA in fine-grained grounds (Eurocode 8);

- Seismic action: peak value of assumed horizontal acceleration of the elastic response spectrum for the lifesaving ultimate limit state: ag/g = 0,20.

For further environmental design conditions, please refer to the proper section of the estimate “General Design Specifications”.
