MOBIL FAST 2 MIX-MC PRO - CEMENTED MIXTURE

Name: MOBIL FAST 2 MIX-MC PRO - CEMENTED MIXTURE
Brand: World Wide Parts
SKU: MOBILFAST2MIXMCPRO
Availability: OutOfStock

mobile plant for the production of structural concrete, cemented mixture and cold asphalt - continuous mixer 150 m³/h - double powder scale with load cells – conveyor belt - hot galvanised

Codice : MOBILFAST2MIXMCPRO

Quantity

Generic Description

N.1 MOBIL FAST 2 MIX-MC PRO.
Mobile plant for the production of structural concrete, cemented mixture and cold asphalt - continuous mixer 150 m³/h - double powder scale with load cells – hot galvanised
N.1 POWDER DIVERTER WITH FLAP GATE - INCLUDING PNEUMATIC CONTROL.
N.1 ANTI-OBSTRUCTION DEVICE completed with rotary paddle level-indicator device installed in the discharge cone of the loading belt.
N.1 EURO-FLOWMIX AUTOMATION KIT FOR 2 MIX-MC PRO For batch or continuous production management - PC, PLC, LASER PRINTER and software package.
N.1 PRINT OPTION FOR CEMENT MIXTURE AUTOMATION - for new systems.
N.1 REMOTE TECHNICAL SUPPORT SERVICE - FREE OF CHARGE DURING GUARANTEE PERIOD.
N.1 UPS (ON-LINE TYPE) - Battery life 6/20 minutes.
N.1 SCREW SPEED CONTROL THROUGH INVERTER FOR MOTORS MAX 30 kW.
N.1 COMMAND CABIN supplied by the purchasing company.
N.1 LIFTING AND UNLOADING KIT FOR MOBILE PLANT.
N.1 FINISHING OF PAINTED COMPONENTS STANDARD COLOUR: RAL 9002 (GREY WHITE) / RAL 7015 (SLATE GREY).
N.1 GENERAL DESIGN SPECIFICATIONS FOR BATCHING PLANTS AND SILOS OF MAXIMUM DIAMETER 3500 mm

All the components are designed for the following environmental conditions:
- Soil roughness: flat area with low vegetation, isolated obstacles 20 times the height from the installation site - Exposition Category II (Eurocode 1);
- Actions on structures:
snow load: 1.00 kN/m2
wind load: v= 28 m/s – 100 km/h;
- Ground type: type B, medium consistency soil, average shear waves velocity in the top 30 m: between 360 m/s and 800 m/s, NSPT > 50 blows / 30 cm in coarsed-grained ground and CU,30 > 250 kPA in fine-grained grounds (Eurocode 8);
- Seismic action: peak value of assumed horizontal acceleration of the elastic response spectrum for the lifesaving ultimate limit state: ag/g = 0,20; - Outside air temperature: within -5° (minimum winter temperature) and +40° (maximum summer temperature), unless for the supply of insulated claddings on the concrete plants and/or the silos;
- Importance Class: Class I, buildings with occasional presence of people (Eurocode 1).
Steel for structural use: S275 or better quality, hot-rolled profiles, in accordance with the EN 10025 standards.
Alloy steel: S235 or better quality, in accordance with the UNI EN 10025 standards.
