MEB 6750/4500 horizontal twin-shaft mixer 4,5 m³ output - EUROMECC

Horizontal twin-axis mixer MEB 6750/4500

- Loading capacity 6,750 l

- Concrete yield 4,500 l

- Mixer load limit by weight: 10,800 kg

- N.2 Mixer motors power 90kW each - tropicalized - IP55 - 400V 50Hz;

- N.2 Planetary angular gearboxes;

- N.1 Homokinetic joint;

- N.4 Pulleys with belts;

- Chromium cast iron tank cover - HB550 - 15 mm thick

- Chromium cast iron mixing blades - HB600 - 27 mm thick

- Square shafts with screwed arms;

- N.2 Side inspection walkways with attachments on tank and chain support.

- No. 1 hydraulically controlled full-length discharge door;

- N.1 Prismatic hydraulic power pack P=3,0KW;

- N.1 Emergency hand pump in case of power failure;

- Automatic greasing system complete with electronic cycle control card + alarms and alphanumeric display;

- 450 mm raised cover with upper inspection doors equipped with gas spring opening system for easy lifting and support of the same during opening;

- Coded limit switch system (CE-compliant) to prevent the doors from opening when the machine has started or the mixing process from starting when the door is open;

- Wiring of auxiliary devices (limit switches to solenoid valves) to the IP55 electrical cable junction box installed on the machine

- Foldable inspection platform with non-slip grating walkway.
