Inclined 28° conveyor belt - length 10000 mm - capacity 180 m³/h - chevron belt - inclination 28°

180 m3/h capacity - truss structure realized in 48 mm dia. tubulars sections.

Chevron Sheet: 10.000 mm length and 800 mm width - class 315 - th. mm 4+2-3 total th. 9 mm

Self-lubricating rollers arranged in set of three - 89 mm diameter

Drive roller diameter 320 mm; covered with anti-slip rubber

7,5 kW three-phase electric motor with orthogonal reducer.

Provided with a belt rabble made up of cemented carbide (WIDIA).

Safety system with stop emergency cable and galvanized protection barrier up to 2 mt from the ground level.
