Inclined 28° conveyor belt - lenght 22000 mm - capacity 260 m³/h - chevron belt - inclination 28°

260 m3/h capacity - truss structure realized in 48 mm dia. tubulars sections.

Chevron Sheet: 22.000 mm lenght and 800 mm width - class 315 - th. mm 4+2-3 total th. 9 mm

Self-lubricating rollers arranged in set of three - 89 mm diameter

Drive roller diameter 510 mm; covered with anti-slip rubber

22 kW three-phase electric motor with orthogonal reducer. Complete with hydraulic coupling.

Provided with a belt rabble made up of cemented carbide (WIDIA).

Safety system with stop emergency cable and galvanized protection barrier up to 2 mt from the ground level.
