Cantilever 2-roll idlers - Belt guide rollers
Two cantilever rollers mounted on a central support, forming a very strong monolithic structure with Ø 15 mm. shafts. 6202 bearings, lubricated for life and protected by ERMEX C6 seals.
Generic Description
The minimum distance in the centre between the two rollers permits the use of extremely flexible belting.
The idler has to be bolted to a flat supporting base (made up for example of a base attachment type 110080) and can be easily positioned for proper belt alignment.
BELT GUIDE ROLLERS
To be mounted in pairs along the conveyor frame, near the belt edges, to stop swerving. They are normally used on automatic belt aligning devices (training idlers).
Technical Data Sheets
Scheda tecnica
Recommended configuration with detailed information
