10L50 - Promag flanged 2" - Ø50
Volume flow: ±0.5 % v.i. ± 2 mm/s (±0.5 % v.i. ± 0.08 in/s);
Measuring range: 9 dm³/min ... 162 000 m³/h (2.5 gal/min ... 1030 Mgal/d);
Pressure range: PN 16, Class 150;
Connection: HART
Ex approvals: cCSAus
Product safety: CE mark, C-tick
Generic Description
10L50 - Promag flanged 2" - Ø50
Flow meter with an optimised and extremely cost-effective weight sensor.
Suitable for applications in the water and waste water industry.
Reduced installation costs - flexible mounting due to flange concept with lap joint (DN < 350/14"). Energy-saving flow measurement - no pressure loss due to cross-sectional constriction. Maintenance-free - no moving parts.
Up to 30% reduction in sensor weight. Nominal diameter: DN 25 ... 2400 (1 ... 90"). Maximum installation length reduced to DVGW/ISO.
Economical - designed for simple applications and direct integration. Safe operation - display provides easily readable process information. Fully compliant with industrial standards - IEC/EN/NAMUR.
2-line display with push buttons. Device in compact or separate version. HART.
Technical Data Sheets
SCHEDA TECNICA - C000N002065
Recommended configuration with detailed information
