Galvanized insulated batcher for ice

Insulated dosing device for ice, dosing on the aggregate loading belt, having the following characteristics:

- geometric capacity: 1,0 m³;

- galvanized batcher covered with insulated panels;

- electro-pneumatic opening through a guillotine valve operated by a pneumatic cylinder with external aluminum coating;

- weighing system with 3 load cells (Soc. Coop. Bilanciai), f.s. 1,000 kg, class C3;

- digital display with automatic dosing even in manual operation, card for analog output 0/10 Volt D.C. for automation connection, RS232 serial port;

- internal lining in HD sp. 10 mm;

- painted carrying frame for positioning on loader belt.

Excluding ice production and feeding system.
