Batcher for metal or synthetic fibers

Batcher for metal or plastic fibers, complete with control panel and weighing system with load cells.

Technical features (type MD 400 Incite or equivalent):

Heigth: 1.600 mm

Diameter: 1.800 mm

Weigth: ar. 1.100 kg

Motor: Nominal power 3000 W (2 X 1500 W)

Capacity: 800-1200 kg for iron fibers or approximatly 150-200 kg for PP fibers

Production capacity: 75-200 kg/min (it depends on the fibers type)

PP/glass fibers: ar. 3-10 kg/min

Electrical feeding: 400 V/50 Hz

Noise Level: 78 dBA (for max 1 m distance)

Management of the following devices: START/STOP - Motor brake - Protection against the overworking of the system

Provided with the conveyor chute.

N.B. Exclusions from the supply and at Customer's charges:

- fibers loading system of the batcher

- steel bearing structure and access ramp staircase (of variable height), unless explicitly offered on the estimate.
