Additional module di n°3 bins for MOBIL FAST 2 MIX-MC PRO

ADDITIONAL MODULE OF N. 3 BINS FOR FAST 2 MIX-MC PRO
HOT GALVANIZED PLANT excluding the frame

STORAGE: N. 3 independent bins of 11 m³ EFFECTIVE GEOMETRIC VOLUME
AGGREGATES LOADING: SUITABLE FOR MECHANICAL SHOVEL
STRUCTURE: Frame length 8.920 mm (12.000 mm with the belt) suitable for transport on deck truck of 13600 mm.

AGGREGATE STORAGE BINS:
N°3 compartments (length 3.300 x 3.300 mm each)
N°3 gates complete with n°2 electro-vibrators

AGGREGATES BATCHING:
N°3 Weighing control systems with n° 4 load cells, end scale 30.000 kg division 20 kg. Digital Display 0/10 Volt D.C. card for analog output to link to automation. Serial port RS232.

EXTRACTOR BELTS:
N. 3 extractor belts with manual motor speed variator. Three-phase electric motor 3 kW, with cooling fan.
Extracting capacity adjusted by inverter. Range of loading output 10-120 m³/h for each belt.
Length 1.750 mm each of them and width sheet 800 mm each of them, class 315, with lateral pleated rubber bands.
Magnetic sensors to control the gears of the belt. Total belts' capacity (range) should be less or at least equal to the nominal range of the mixer.

HORIZONTAL NECK CONVEYOR BELT - CONNECTING BINS TO FAST 2 MIX-MC PRO:
Capacity 180 m³/h - Sheet length 12.000 mm and width 800 mm – class 315 – th. mm 4+2; 3 sheet (total th. 9 mm)
Self-lubricating rollers arranged like a tern (diameter 89 mm)
Driving roller diameter 420 mm covered with anti-slip rubber
Three-phase electric motor 5,5 kW – orthogonal gear box
Galvanized safety barrier.
Safety system with emergency cable and manual reactivation.

ADDITIONAL CONTROL PANEL installed on board the additional module 2 MIX-MC PRO and interfaced with the main module.

THICKNESSES:
Sidepanels – Separators 4 mm
Aggregate gates 6 mm.
Reinforcements applied on the points subject to higher wear and solicitations 8-12 mm.

INCLUDING HARDWARE AND SOFTWARE INTEGRATION -

INCLUDING ADJUSTMENT OF TRAFFIC LIGHT SYSTEM FOR ADDITIONAL MODULE.

FINISHING:
The aggregates panel, separators and gates of the aggregate storage tanks are hot-dip galvanized.
The remaining components of the system are painted according to the following cycle:
- Preparation: P1 preparation degree according to ISO 8501.
- Varnishing: Application of high solid acrylic enamel with semi-gloss zinc phosphate with reduced solvent content, resistant to acids, alkalis, greases and oils; average thickness 160 µm.

Other complementary accessories are also painted, unless otherwise specified in the individual items.
