Planetary gearbox 3 13 i26.4 Single shaft position:B1 Output shaft Ø120 X_3 13M R 2 26.4 FZ B1 RA
Planetary gearbox 3 13 i26.4 Single shaft position:B1 Output shaft Ø120 X_3 13M R 2 26.4 FZ B1 RA
Previous keyboard_arrow_left
Next keyboard_arrow_right
zoom_in
Planetary gearbox 3 13 i26.4 Single shaft position:B1 Output shaft Ø120 X_3 13M R 2 26.4 FZ B1 RA
Planetary gearbox 3 13 i26.4 Single shaft position:B1 Output shaft Ø120 X_3 13M R 2 26.4 FZ B1 RA

Planetary gearbox 3 13 i26.4 Single shaft position:B1 Output shaft Ø120 X_3 13M R 2 26.4 FZ B1 RA

Planetary gearbox 3 13  i26.4 Single shaft position:B1 Output shaft Ø120 X_3 13M R 2 26.4 FZ B1 RA

Codice : C151A000061
SKU: WPJB00043021
Quantity

Generic Description

Epicyclic series 3

Size 13

Angular

Reduction stages 2

Reduction ratio 26.4

Output: Splined female shaft profile N120x3 din 5480

Including splined profile N120x3 din 5480 L= 170 mm

With oil plug M30 x 2 Windowed for level viewing

Input: Connection flange with a cardan shaft

Mounting position B1

Rotation Counterclockwise

Recommended configuration with detailed information
