Generic Description
MOBILE RECYCLING PLANT EURO-WASH
The mobile recycling plant BR10 is the best solution to recycle concrete and perform truck mixer washing operations on a temporary production site, in full compliance with environmental regulations.
The plant does not require any civil work for installation, and the erection time takes only a few hours.
The plant is entirely galvanized, composed of the following parts:
Nr. 1 CONCRETE RECYCLING MACHINE EURO-WASH 10
Features:
-
concrete disposal capacity: 11 cu.m/h
-
mortar disposal capacity: 4 cu.m/h
Nr. 1 DISCHARGE HOPPER FOR CONCRETE MIXERS SERIES L = 3000 mm
Nr. 1 DIRTY WATER TRANSFER SYSTEM (FROM BR TO STORAGE TANK)
Nr. 1 STORAGE WATER TANK – Capacity 25 m³
Nr. 2 AGITATORS ECO 1100 – 4 kW
Nr. 1 BOOM FOR CLEAN AND RECYCLED WATER DELIVERY TO THE TRUCK MIXER
Nr. 1 RECYCLING SYSTEM CONTROL BOARD
Nr. 1 EXTERNAL PUSH-BUTTON STRIP FOR CYCLE START/STOP
Nr. 1 AMPEROMETRIC CONTROL FOR SEPARATOR FUNCTION
Nr. 2 SUBMERSIBLE PUMP
Nr. 2 WATER PUMP LIFTING SYSTEMS
Technical Data Sheets
Brochure - EUROECO-EUROWASH
Recommended configuration with detailed information
