Electrical panel for washing water recycling and aggregate recovery

Electrical Control Panel of command with PLC.

Electrical Panel for management of washing of n. 1 truckmixer, with push-button on board for the cycle start.

ABB Carpentery (or similar)

Protection degree IP 65, synoptic panel of command coloured completed with selectors, start up, pilot light. Disconnecting switch.

Electronic module of auxiliary protection, magnetothermic protection. Indicator of tension inside the panel.

Manual emergency mushroom head button. Start up auxiliary and key. Amperometer and Voltmeter. Terminal board for cables connection. Telemecanique components. PLC for automatic management for truck mixers washing and for other components washing on the stop phase. Internal space not cabled for future expansions at the 10%. Feeding tension 400V.

The panel is made of: electric diagram completed, diagram for terminal board connection, conformity with Laws 2006/42/CE – 2006/95/CE – 2004/108/CE and other changes.

Pulse-Buttons starting up cycle.
